STM32F302C8T6 Nucleo-64

Clock Configration

• Timer Clock
  • APB1 Clock Bus  : F max = 36Mhz
    • Timer 2 / PWM , Timer6,
    • SPI2 / SPI3 / USART2 / USART3 / I2C1 / I2C2 / I2C
  • APB2 clock bus :  F max = 72 Mhz
  • Timer1 / PWM / Timer 15 / Timer16 / Timer17,



Features

• ARM® 32-bit Cortex®-M4 CPU with FPU (72 MHz max.)
• VDD, VDDA voltage range: 2.0 to 3.6 V
• 4 to 32 MHz crystal oscillator / Internal 8 MHz RC with x 16 PLL option
• 7-channel DMA controller supporting timers, ADCs, SPIs, I 2Cs, USARTs and DAC
• 1 x 12-bit DAC channel with analog supply from 2.4 to 3.6 V
• Up to 9 timers
• Communication interfaces :
  • – Three I2Cs with 20 mA current sink to support Fast mode plus
  • – Up to 3 USARTs, 1 with ISO 7816 I/F, auto baudrate detect and Dual clock domain
  • – Up to two SPIs with multiplexed full duplex I2S
  • – USB 2.0 full-speed interface – 1 x CAN interface (2.0B Active) – Infrared transmitter
• Serial wire debug (SWD), JTAG
• Block Diagram
